Hydrotech ZS Consulting

NX8X

Good replacement for NX7 and NX8

8” display

Ultra rugged design and modular structure.

From field use to desktop operation

Powerful enough to run the most demanding applications.

Field rugged design and modular structure.

Specifications for NX8X:

Dimensions:

• 225 mm x 147 mm x 24 mm (8.8” x 5.7” x 0.9”)

Weight:

• 990 g (2.18 lbs)

Processor:

• Intel® Pentium® N3710 1.60 GHz (2.56 GHz boost) 64-bit quad-core.

Graphics:

• Intel HD Graphics 405

RAM and Storage:

• 8 GB / 128 GB

Operating System:

• Windows 10 Enterprise (64-bit)

Display:

• 8” capacitive multi-touch
• 1280×800 pixels
• Sunlight readable, 600 nits
• Glove/rain mode
• Chemically strengthened glass

Buttons:

• Front
• Power, lock/touch mode, menu, home, F1, F2

Battery:

• Standard
• 7.6V 5900 mAh (44.84Wh)
• Hot-swappable
• Extended
• 7.2V 10350 mAh (74.52Wh)
• Hot-swappable

Ports:

• DC power jack
• 2x USB A 3.0
• Micro HDMI
• Docking connector
• Back connector for expandability
• Side expansions
• 1x micro SDXC
• 1x micro SIM

Communication:

• Cellular (WWAN)
• 2G, 3G, 4G/LTE, Verizon LTE
• Sierra EM7355 (NA. M.2 Type)
• Sierra EM7305 (EU. M.2 Type)
• Sierra EM7455 (Verizon. M.2 Type)
• *Data only
• Wireless LAN
• 2.4 GHz + 5 GHz
• 802.11 ac, a/b/g/n
• PAN
• BT V4.2
• Audio
• Front-facing speaker
• Microphone

Positioning:

• Dedicated u-blox GNSS receiver
• GPS/GLONASS/Galileo/Beidou

Cameras:

• Rear
• 8 megapixel with autofocus and flash
• Front
• 2 megapixel

Sensors:

• Ambient light

Environment:

• Operating
• -20°C to 60°C (-4°F to 140°F)
• MIL-STD-810G, Method 501.5 Procedure II
• Storage
• -40°C to 70°C (-40°F to 158°F)
• MIL-STD-810G, Method 501.5/502.5 Procedure I
• Drop / Shock
• 26 drops from 1.2 m (4 ft)
• MIL-STD-810G, Method 516.6 Procedure IV
• Vibration
• MIL-STD-810G, Method 514.6 Procedures I, II
• Sand / Dust
• IP65, IEC 60529
• Water
• IP65, IEC 60529
• Humidity
• 0 ～ 95% (non-condensing)
• MIL-STD-810G, Method 507.5
• Altitude
• 4572 m (15.000 ft)
• MIL-STD-810G, Method 500.5 Procedure I

Additional Security:

• TPM V2.0
